SuperPro Viton PS200 Shaft Seal In stock$21⁹⁹

SuperPro 200V-9 Viton PS-200 pump shaft seal

SuperPro Viton PS200 Shaft Seal

Name: SuperPro Viton PS200 Shaft Seal
Brand: SuperPro
SKU: SPG-60-0202
Price: 21.99 USD
Availability: InStock

Ask a questionMPN 200V-9

$21⁹⁹

In stock

Get volume pricing Request a quote

30 day returns · Easy, with prepaid labels provided

Quick overview

Viton elastomer The Viton version of the PS-200 seal, chosen where a standard buna seal is not enough.
Seal 200 pattern Built to the widely used PS-200 shaft seal footprint.
Polished cup mounted seat The stationary half is a polished seat in a mounted cup, ready to press into the seal plate.
Sized for a 5/8 inch shaft Measure the motor shaft before ordering, since the 200 series also appears in other shaft sizes.
Stops the drip behind the pump A weeping shaft seal is the usual reason for water tracking down the motor end of the pump.
Two piece set Rotating half and seat come together, so the whole seal is replaced at once.

Full description and specifications ↓

Need a hand?

Bilingual support from pool professionals.

(888) 751-8084Call Chat with a techChat Email usEmail

Frequently bought together

Current item Select SuperPro Viton PS200 Shaft Seal

SuperPro

Viton PS200 Shaft Seal

$21⁹⁹

Select

SuperPro

Superflo / Supermax Pump Repair Kit

$22⁹⁹

Select

SuperPro

Viton Whisperflo Pump Seal Rebuild Kit

$39⁹⁹

Select

SuperPro

Jandy SHPF and SHPM Series Viton Seal Kit

$50⁹⁹

Select

SuperPro

Jandy JHP Pump Seal Kit

$40⁹⁹

Select

SuperPro

Hayward Matrix Pump Seal Kit

$22⁹⁹

Select

SuperPro

Sta-Rite P2R Pump Seal Kit after 1997

$52⁹⁹

Subtotal

Similar products

Other products people compare with this one.

SuperPro 1000V-9 Viton heavy duty pool pump shaft seal for a 5/8 inch shaft

SuperPro Viton Heavy Duty Shaft Seal, 5/8" Shaft$15⁹⁹

U.S. Seal PS-3865R heavy duty 5/8 inch Viton carbon pump shaft seal

U.S. Seal Heavy Duty Salt and Ozone Service Shaft Seal, Viton Carbon$15⁹⁹

SuperPro 201 pump shaft seal assembly for 3/4 inch shaft motors

SuperPro 201 Seal Assembly for 3/4" Shaft Motors$11⁹⁹

SuperPro GO-KIT14-9 seal kit for Jacuzzi Magnum pumps

SuperPro Jacuzzi Magnum Pump Seal Kit$30⁹⁹

U.S. Seal PS-3890 generic shaft seal assembly for Hayward Northstar pumps

U.S. Seal Shaft Seal Assembly (Generic)$22⁹⁹

SuperPro 201V-9 pump shaft seal assembly, replaces 37400-0028S

SuperPro Seal Assembly (37400-0028S)$18⁹⁹

Sta-Rite U109-93SS old style pump shaft seal

Sta-Rite Shaft Seal, Old Style$26⁹⁹

U.S. Seal PS-601 shaft seal assembly for a 3/4 inch pump shaft

U.S. Seal Shaft Seal Assembly, 3/4" Shaft$19⁹⁹

U.S. Seal PS-2131 pump shaft seal assembly

U.S. Seal Shaft Seal Assembly PS2131$15⁹⁹

Pentair Sta-Rite OEM Shaft Seal Without Copper Insert | 17304-0100S$21⁹⁹

Aladdin GO-KIT 71 seal kit for the old style Polaris PB4-60 booster pump

Aladdin GO-KIT 71 Seal Kit for Polaris PB4-60 Booster Pump$16⁹⁹

Pentair 357872 IntelliFlo3 and IntelliPro3 pump rebuild seal set kit

Pentair IntelliFlo3 and IntelliPro3 Pump Rebuild Seal Set Kit$31⁹⁹

Jandy R0449100 pump lid seal gasket with o-ring

Jandy Pump Lid Seal Gasket with O-Ring$20⁹⁹

Pentair 355619Z SuperFlo and Pinnacle seal bracket O-ring

Pentair SuperFlo Seal Bracket O-Ring$17⁹⁹

Pentair 351446 WhisperFlo XF seal plate o-ring

Pentair WhisperFlo XF Seal Plate O-Ring$12⁹⁹

Pentair 357099Z square ring for the seal plate on Max-E-Pro and IntelliPro pumps

Pentair Square Ring, Seal Plate, Max-E-Pro / IntelliPro$19⁹⁹

U.S. Seal PS-3868 heavy duty mechanical pump seal set

U.S. Seal Heavy Duty Seal Assembly$19⁹⁹

Hayward SPX0125F plastic motor shaft slinger for Super and Super II pumps

Hayward Slinger for Motor Shaft$13⁹⁹

SuperPro GO-KIT6-9 rebuild kit for Sta-Rite Max-E-Glas and Dura-Glas pumps

SuperPro Max-E-Glas/Dura-Glas Pump Rebuild Kit$23⁹⁹

SuperPro GO-KIT1-9 rebuild kit for Hayward Max-Flo pumps

SuperPro Rebuild Kit for Hayward Max-Flo Pump$22⁹⁹

Product details

The SuperPro 200V-9 is a Viton shaft seal built to the Seal 200 (PS-200) pattern, one of the most common shaft seal footprints in pool pumps. It is supplied as a set, with a rotating half and a polished seat already mounted in its cup.

Why Viton

The elastomer is what usually decides how long a shaft seal lasts. Viton holds up better against heat and aggressive water chemistry than a standard seal, so it is the sensible upgrade on a pump that has chewed through more than one seal, or one that runs hot.

Before you order

This seal is sized for a 5/8 inch shaft. Pull the motor and measure the shaft rather than guessing, because the 200 series is produced in more than one shaft size and the wrong one will not seat.

A shaft seal is the part that keeps water in the wet end and out of the motor. If water is tracking down the back of the pump while the lid and the unions stay dry, this is the part to change, and it is worth doing before the bearings take the damage.

Specifications
Brand	SuperPro
Manufacturer part number	200V-9
UPC	601402265549
Type	Pump shaft seal
Elastomer	Viton
Seal series	Seal 200 (PS-200)
Seat	Polished cup mounted seat
Shaft size	5/8 inch
Shipping weight	0.1 lb
Ships	Parcel
